ChipProg Device Programmers
Graphical User Interface
The ChipProgUSB graphical user interface (GUI) elements include:
Menus - global and local
Windows
Toolbars - global and local
Setting Dialogs
Hot Keys
Context-sensitive help prompts
GUI featured with several useful additions specifically created for the ChipProg operations.
To make your operations with the ChipProgUSB program easier we highly recommend to learn the
chapters Menus and Windows in full. You will be able to use the tools much more effectively.
User Interface Overview
ChipProgUSB features the standard Windows interface with several useful additions:
1. Each window has its own local menu (the shortcut menu). To open this menu, click the right mouse
button within the window area or press Ctrl+Enter or Ctrl+F10 . Each command in the menu has a hot
key shortcut assigned to the Ctrl+<letter> keys. Pressing the hot key combination in the active window
executes the corresponding command.
2. Each window has its own local toolbar. The window’s toolbar buttons give access to most of the
window’s local menu commands. The specialized window toolbar buttons operate only within the
specialized window. The main window has several toolbars that can be turned on or off (in the
Environment dialog, the Toolbar tab ).
3. Each toolbar button has a short prompt: when you place the cursor over a toolbar button for two
seconds, a small yellow box appears nearby with a short description of the button’s function.
4. To save screen space, you can hide any window’s title bar. To do this, use the Properties command of
the local menu. You can identify the ChipProgUSB windows by their contents and position on the
screen (and, if you wish, by color and font). When the title bar is hidden, you can move the window as if
the toolbar were the title bar: place the cursor on the free space of the toolbar, press the left mouse
button and drag the window to a new position.
5. You can open any number of windows of the same type. For example, you can open several windows.
6. Every input text field of any dialog box has a history list. ChipProgUSB saves them when you close a
development session. Then a previously entered string can be picked from the history list.
7. All input text boxes in the dialogs feature automatic name completion.
8. OK button. This is convenient when you need to change only one option in the dialog and then close it.
Toolbars
The ChipProgUSB program opens a few toolbars on top of the main window (see below).
? 2010 Phyton, Inc. Microsystems and Development Tools
